1000 W Class D lightweight amplifier
LF Transducer: (1) EVS-15K, 381mm (15”) Woofer
HF Transducer: DH-1K, 39mm (1.5”) Titanium Diaphragm Compression Driver
44 Hz – 20 kHz frequency range; 134 dB max SPL
Rugged wood cabinet
9-ply, 15mm Plywood, Internally Braced
Coverage (Nominal -6 dB): H° 90 °
Coverage (Nominal -6 dB): V° 50 °
Crossover Frequency: 1.7 k Hz
Connector Type: (2) XLR/TRS Combo Jacks, (1) Stereo RCA, (1) XLR Link Output
Grill: 18GA Steel with Black Powdercoat
Height: 708 mm (27.87")
Width: 432 mm (17.01")
Depth: 382 mm (15.04")
Weight Net: 24.3 kg (53.57 lbs)
